China factory of fully automatic aging test line for mobile phones
2500000.0 INR/Set
Product Details:
- Color black
- Interface Type Customer customization
- Product Type burn-in test equipment
- Material Cold-rolled sheet
- Test Range Mobile phone
- Operate Method Computer control
- Click to view more
X
China factory of fully automatic aging test line for mobile phones Price And Quantity
- 1 Set
- 2500000.0 INR/Set
China factory of fully automatic aging test line for mobile phones Product Specifications
- Cold-rolled sheet
- Mobile phone
- 7000 Kilograms (kg)
- Customer customization
- Aging test equipment
- burn-in test equipment
- Computer monitoring
- burn-in test equipment
- black
- Computer control
China factory of fully automatic aging test line for mobile phones Trade Information
- 2500000
- Telegraphic Transfer (T/T)
- 2 Set Per Month
- 2 Months
- Yes
- Contact us for information regarding our sample policy
- Packed in wooden cases
- CE,ROHS
Product Description
Scope of application
Mobile phone LED power supply, new energy OBC, PC power supply, server power supply,
TV power supply, photovoltaic inverter, high-power industrial power supply, etc
Performance parameters
| Basic information Model | Equipment Model | CPET-ME4000080T |
| Units Per Hour(UPH) | 3200PCS/h | |
| Product Power | 100W/CH | |
| Equipment Size | L=5600mm,W=2250mm,H=1600mm | |
| Equipment Weight | Around 7000KG | |
| Related Information of Burn-in line |
Burn-in Room Capacity | 1600PCS |
| Burn-in Time | 2H | |
| Burn-in Ply Number | 8 | |
| Transfer mode | Modular splicing manipulator handling | |
| Burn-in Line Temperature Control syst |
Cooling Circulation Mode | Forced air cooling:fan+frequency convertwe+air duct |
| Control Scope and Precision | The temperature control cope:adjustable from room temperature to 60C.The control precision is 5C | |
| Temperature Rise Rate | Able to rise to more than 45C in 20 minutes | |
| Burn-in Line Electronic Control system |
Product and Load Properties | Optional |
| Load Properties | Optional | |
| Burn-in Voltage Input | Support up to 6 voltages | |
| Protection and Alarm | Control power supply independently and added with protection and equpment including overheating and overload protection,earth leakage circuit breaker,waring light,emergency switch,etc | |
| Hardware Demand Description | Independent computer host, display burn-instate, monitor output should be voltage, current,power and soon | |
| Software Monitor Demand | Compile different Burn-in programs according to different products, realize voltage switching, impact, switching cycle, current setting, temperature setting and other parameters | |
| Burn-in Management Demand | The OK and NG judgment monitoring interface can directly understand that the data can be saved according to the required data format (TXT, EXCEL), which is convenient for query and download | |
| Test Station Related Informat |
Test Station Types | Install the product + electrified initial test + high voltage + ATE + Burn-in + ATE + take the product, automatic test Burn-in system, Unit combination system |
| Test Mode | Optional | |
| Test Data Processing | Optional | |
| Test Instruments | Optional | |
| Connection Mode | Optional | |
| Burn-in & Test Jig | Jig Size | W260mm*D460mm*H82 |
| Interface Mode | USB | |
| The Commmon Usage | Shared by burn-in and test | |
| Weight | 1KG | |
| Main Electric Control System | Protection Equipment | Possessing independent and segmentation main switches.Having independent ground protection and electricity leakage protection devices |
| Power Demands | According to the actual planning | |
| Air source requirements | 0.5-0.8MPa |
